HandiSwage Cable Railing
The HandiSwage™ System is an easy to use cable railing product utilizing fittings that are an adaption of traditional swage fittings. They can be attached to cable using Atlantis Rail's hand swage tools. The HandiSwage™ System combines the aesthetic appeal, quality and durability of the RailEasy™ cable components with the convenience and economy of 1/8" or 5/32" cable. All HandiSwage™ components are made from grade 316L stainless steel for durability and corrosion resistance.
Atlantis Cable Railing SC offers standard rail heights of 36″ or 42″ for straight sections.
Rail height for stair sections is available in 36″ only.
Note: Railing heights are offered in these dimensions due to nationwide building codes. However, Atlantis Rail can supply custom heights/lengths upon request.
Between Posts Length
Atlantis Rail recommends staying within 4′ section lengths to maintain structural integrity. if section lengths exceed 4′, Atlantis Rail offers a Cable Stabilizer Kit to minimize cable deflection.
The cable is spaced on posts at 3″ on-center to comply with nationwide building codes
Vinyl Post Components – White vinyl sleeves, fitting over a 4×4 post, are available in lengths of 48″. Cut post sleeves to appropriate application height. Colonial style white vinyl post cap and base are also available as railing add-ons.
Micro Star™ Lighting – Micro Star™ LED lights can be integrated into the top rail for sublet illumination. Also, the Micro Star™ LED Post Cap fits over standard 4×4 vinyl sleeves and provides sufficient lighting for stairs and walkways.
